AEM Tip: Learning from a “Segment not found” Error

Exadel Digital Experience Team Tech Tips June 11, 2019 6 min read

Tags

AEM is constantly evolving, offering more new features with each new release. But, with so many new features, sometimes new platform features can affect existing home-grown functionality, even when they don’t seem to be related to each other.

Here’s an example. One day, after migrating to AEM 6.4, one of our public services available at /services/acme/myservice.json stopped working, and the following message appeared in the logs:

Copy Code

11.09.2018 17:59:24.403 *ERROR* [12.345.6.7 [1536688764343] GET /services/acme/myservice.json HTTP/1.1] org.apache.jackrabbit.oak.segment.SegmentNotFoundExceptionListener Segment not found: e851f378-0da9-4f99-a34b-2d2e036a40b1. SegmentId age=344865269ms,segment-generation=GCGeneration{generation=7,fullGeneration=2,isCompacted=false}
org.apache.jackrabbit.oak.segment.SegmentNotFoundException: Segment e851f378-0da9-4f99-a34b-2d2e036a40b1 not found

See less

After some investigation it appeared that:

The issue happens after AEM has performed an online revision cleanup
The issue goes away after an AEM server restart

In fact a Sling Servlet behind /services/acme/myservice.json was referencing and using the com.acme.www.service.impl.MyServiceImpl service. We searched through the log files and found the following messages related to that MyServiceImpl service:

Copy Code

11.09.2018 18:57:05.949 *WARN* [qtp1796865675-2034] org.apache.jackrabbit.oak.jcr.session.RefreshStrategy This session has been idle for 23 minutes and might be out of date. Consider using a fresh session or explicitly refresh the session.
java.lang.Exception: The session was created here:
       at org.apache.jackrabbit.oak.jcr.session.RefreshStrategy$LogOnce.(RefreshStrategy.java:170) [org.apache.jackrabbit.oak-jcr:1.8.2]
       at org.apache.jackrabbit.oak.jcr.repository.RepositoryImpl.login(RepositoryImpl.java:285) [org.apache.jackrabbit.oak-jcr:1.8.2]
       at org.apache.jackrabbit.oak.jcr.repository.RepositoryImpl.login(RepositoryImpl.java:226) [org.apache.jackrabbit.oak-jcr:1.8.2]
       at org.apache.jackrabbit.oak.jcr.session.SessionImpl.impersonate(SessionImpl.java:275) [org.apache.jackrabbit.oak-jcr:1.8.2]
       at com.adobe.granite.repository.impl.CRX3SessionImpl.impersonate(CRX3SessionImpl.java:149) [com.adobe.granite.repository:1.4.88]
       at org.apache.sling.jcr.base.AbstractSlingRepository2.createServiceSession(AbstractSlingRepository2.java:201) [org.apache.sling.jcr.base:3.0.4]
       at com.adobe.granite.repository.impl.SlingRepositoryImpl.createServiceSession(SlingRepositoryImpl.java:135) [com.adobe.granite.repository:1.4.88]
       at org.apache.sling.jcr.base.AbstractSlingRepository2.createServiceSession(AbstractSlingRepository2.java:171) [org.apache.sling.jcr.base:3.0.4]
       at org.apache.sling.jcr.base.AbstractSlingRepository2.loginService(AbstractSlingRepository2.java:381) [org.apache.sling.jcr.base:3.0.4]
       at org.apache.sling.jcr.resource.internal.helper.jcr.JcrProviderStateFactory.createProviderState(JcrProviderStateFactory.java:116) [org.apache.sling.jcr.resource:3.0.8]
       at org.apache.sling.jcr.resource.internal.helper.jcr.JcrResourceProvider.authenticate(JcrResourceProvider.java:304) [org.apache.sling.jcr.resource:3.0.8]
       at org.apache.sling.jcr.resource.internal.helper.jcr.JcrResourceProvider.authenticate(JcrResourceProvider.java:76) [org.apache.sling.jcr.resource:3.0.8]
       at org.apache.sling.resourceresolver.impl.providers.stateful.ProviderManager.authenticate(ProviderManager.java:161) [org.apache.sling.resourceresolver:1.5.34]
       at org.apache.sling.resourceresolver.impl.providers.stateful.ProviderManager.getOrCreateProvider(ProviderManager.java:87) [org.apache.sling.resourceresolver:1.5.34]
       at org.apache.sling.resourceresolver.impl.providers.stateful.ProviderManager.authenticateAll(ProviderManager.java:129) [org.apache.sling.resourceresolver:1.5.34]
       at org.apache.sling.resourceresolver.impl.ResourceResolverImpl.createControl(ResourceResolverImpl.java:138) [org.apache.sling.resourceresolver:1.5.34]
       at org.apache.sling.resourceresolver.impl.ResourceResolverImpl.(ResourceResolverImpl.java:100) [org.apache.sling.resourceresolver:1.5.34]
       at org.apache.sling.resourceresolver.impl.ResourceResolverImpl.(ResourceResolverImpl.java:94) [org.apache.sling.resourceresolver:1.5.34]
       at org.apache.sling.resourceresolver.impl.CommonResourceResolverFactoryImpl.getResourceResolverInternal(CommonResourceResolverFactoryImpl.java:263) [org.apache.sling.resourceresolver:1.5.34]
       at org.apache.sling.resourceresolver.impl.ResourceResolverFactoryImpl.getServiceResourceResolver(ResourceResolverFactoryImpl.java:96) [org.apache.sling.resourceresolver:1.5.34]
       at com.acme.www.service.impl.MyServiceImpl.activate(MyServiceImpl.java:99) [com.acme.www.web-services:1.23.4.5]

See less

When we checked the MyServiceImpl code, we saw this anti-pattern:

Copy Code

@Reference
private ResourceResolverFactory resourceResolverFactory;

@Activate
protected void activate(final ComponentContext componentContext) {
    try {
        //Resource Resolver is created on a component activation
        this.resourceResolver = resourceResolverFactory.getServiceResourceResolver(resourceResolverParams);
        ...
    } catch (Exception e) {
        ...
    }
}

public void perform() {
    this.resourceResolver.resolve(...);
}

See less

As you can see above, a resource resolver was created once upon component activation and was alive while the component was alive. That caused the idle session issue (see the stack trace above). The long-lived resource resolver was referencing a segment that was altered by online revision cleanup. Therefore, the subsequent calls of the perform() method of MyServiceImpl were causing the “Segment not found” error that we noted at the beginning of this post.

As a response, we followed the best practice of creating a resource resolver when it’s required and closing it when it’s not needed anymore. So, we refactored MyServiceImpl to look like this:

Copy Code

@Reference
private ResourceResolverFactory resourceResolverFactory;

@Activate
protected void activate(final ComponentContext componentContext) {
    //Resource Resolver creation was removed from here
    ...
}

private void perform() {
    try (ResourceResolver resourceResolver = resourceResolverFactory.getServiceResourceResolver(...)) {
        resourceResolver.resolve(...);
    } catch (Exception e) {
        ...
    }
}

See less

For more information about handling the lifecycle of resource resolvers, please see our previous post on Creating a Helper to Close Sling Resource Resolver Instances.

Author: Denis Glushkov
